What Is an Communication PCB?
In the field of communications, communication PCB boards play a crucial role in various applications such as wireless networks, transmission networks, data communications, and fixed-line broadband. These PCB boards encompass a range of products including backplanes, high-speed multilayer boards, high-frequency microwave boards, HDI boards and multi-function metal substrates.
PCB requirements in the communications field are divided into subdivisions such as communication devices and mobile terminals. Communication equipment is mainly used for communication infrastructure for wired or wireless network transmission. Including communication base stations, routers, switches, etc. Communication equipment mainly uses high-layer PCB boards, of which 8-16 layers account for about 42%. And mobile terminals are mainly HDI and flexible boards.
Communication PCB Advanced Manufacturing Capabilities
We have an experienced team of communication PCB design engineers and modern production lines capable of handling various communication PCB assembly needs—from simple single-layer boards to complex multilayer designs. Our technical strengths include:
High-Frequency Design Expertise
Proficient in microwave band (700MHz–5GHz) circuit design for optimal 5G device performance.
Precision Machining
Minimum aperture of 0.2mm, trace width/spacing of 4–6 mil, supporting high-density interconnects.
Multiple Surface Finishes
Options include HASL (Lead-Free), ENIG (Immersion Gold), OSP, and Immersion Silver.
Strict Quality Control:
Full-process quality monitoring from raw materials to finished products.
Communication PCB 5G construction features
Communication PCBs in 5G construction have significant features and requirements due to the high-speed and high-frequency nature of 5G technology. These features drive the demand for communication boards, especially in the construction of 5G base stations.
Increased Base Station Quantity: The number of 5G base stations is much larger compared to current 4G base stations. Additionally, the deployment of micro base stations in blind spot areas further contributes to the demand for communication PCB boards.
Industrial Control Environment: Communication PCBs are utilized in both wired and wireless communication equipment within industrial control environments. Wired communication equipment includes serial communication, professional bus-type communication, industrial Ethernet communication, and various communication protocol conversion equipment. Wireless communication equipment encompasses wireless APs, wireless bridges, wireless network cards, wireless lightning arresters, antennas, and other related devices.
High-Frequency and High-Speed Requirements: The RF (Radio Frequency) part of communication PCBs operates at relatively high frequencies, while the baseband part handles digital signals with very high data rates. These characteristics impose stringent material requirements on the PCBs. Some components may also require boards with ceramic substrates to meet specific performance needs.
Complex PCB Design and Processing: Communication PCBs often have dozens of layers, including through-hole plates. They may require a back-drilling process to ensure precise signal integrity and minimize signal reflection.
Our experienced engineers and state-of-the-art facilities enable us to handle the complex design and processing needs of communication PCBs. With the ability to manufacture multi-layered PCBs with precision and efficiency, including through-hole plates and back-drilling processes, we ensure excellent signal integrity and minimize signal reflection.
